1. Serial Ports 6. Reset button

(use unfolded paperclip

to press)

2. Wall mount screw hole

(on underneath of box)

7. Ethernet port connection -

10BaseT / 100BaseTX

3. Serial Port(s) LED 8. Status LED

4. Ethernet LED 9. DIN Rail kit holes

(on underneath of box)

ES-357/ES-246/ES-257/ES-320 - Power Input 5-30V DC, 1.8W Max / 1.0W Typical

ES-313 -

Power Input 5-30V DC, 2.6W Max / 1.2W Typical

2. Hardware

3 38 8
